Brand: JONHON
JONHON UQD Series Quick Disconnects (UQD02–UQD08)
QuickDisconnectchinajonhonliquid coolingocpquick disconnectuqd
Project-based pricing — no public retail price.
Engineering quote in 24–48 h
Tell us the quantity, site power/cooling context and delivery country — our supplier desk returns a spec'd offer, not a generic price list.
Overview
OCP-standard UQD quick disconnects for server-to-manifold and manifold-to-piping connections, from the only Chinese contributor to both OCP UQD V1.0 and V2.0.
- Bore sizes UQD02–UQD08, rated flow 2.1–17.8 L/min per branch
- Working temperature −40 °C to +150 °C; standard rating 0.9 bar (13 psi), small sizes to 20 bar (290 psi)
- Maximum spillage on disconnect below 0.07 ml — drip-free switchover
- Push-pull locking, one-handed mating; red/blue supply-return colour coding
- Stainless-steel body; 5,000 mating cycles rated
