Brand: SWEP
SWEP B120 Brazed Plate Heat Exchanger
HeatExchangerbrazedcompactcoolingheat-exchangerplateswep
Project-based pricing — no public retail price.
Engineering quote in 24–48 h
Tell us the quantity, site power/cooling context and delivery country — our supplier desk returns a spec'd offer, not a generic price list.
Overview
Copper-brazed plate heat exchanger for compact water/water and water/oil duties in liquid-cooling circuits.
- AISI 316 stainless steel plates with copper brazing; 2 in ISO-G or 42 mm port connections
- Maximum operating pressure 35 bar(g) at 20 C and 27 bar(g) at 225 C; test pressure 51 bar(g)
- Working temperature range -196 C to 225 C
- Water/water duty of roughly 290 to 860 kW on the 160-plate version, depending on the temperature programme
- Recommended maximum flow about 24.5 m3/h on the 160-plate unit, sized to hold pressure drop near 30 kPa
